GRS EasyGraver Sharpening Fixture 105° V Point - 003-701

Brand: GRS

Subtotal: £192.00 Price: £192.00 + VAT if applicable

SKU: TB993701 Packaged weight: 0.348kg
Please note this product is excluded from any discounts or promotional offers.
This tool saves time during the sharpening process to increase profitable moments spent at the bench.

Many new setter's and engravers are challenged with understanding and consistently producing accurate sharpening results.

The design of the EasyGraver Sharpening Fixture is based on the standard geometries that we observed in use by hundreds of engraving artists and jewellers throughout the world over many years.

Two separate models are available: 120˚ or 105˚, both for creating V-point gravers. For hand engravers and jewellers who currently use other geometries, the time it takes to adjust to these presets is outweighed by the benefits of accuracy and efficiency.

Please note that the Post Assembly IS NOT INCLUDED and must be purchased separately.

Post positions #1 and #2 are for truing or reshaping the base of the graver for a 120 or a 105 degree V-point. The side post positions, #3 and #4, are then used to sharpen a parallel heel. After the heels are sharpened, the center post position (#5) allows the user to sharpen a face angle and easily adjust the length of the heel.
