Rough Pinion Wire
See below for options.
Our Range Of Pinion Wire, Manufactured In EN8 or EN24 Steel.
Available In 6, 7 & 8 Leaves and Module 0.45 to 0.75
CP281 - Module 0.45, Leaves 6. A=1.12mm, B=10mm, C=3.36mm, D=28mm & E=50mm
CP282 - Module 0.50, Leaves 6. A=3.74mm, B=1.25mm, C=15mm, D=55mm & E=95mm
CP283 - Module 0.55, Leaves 6. A=4.11mm, B=1.37mm, C=15mm, D=55mm & E=95mm
CP285 - Module 0.65, Leaves 6. A=4.86mm, B=1.62mm, C=15mm, D=55mm & E=95mm
CP286 - Module 0.70, Leaves 6. A=5.23mm, B=1.75mm, C=15mm, D=55mm & E=95mm
CP287 - Module 0.75, Leaves 6. A=5.61mm, B=1.87mm, C=15mm, D=55mm & E=95mm
CP288 - Module 0.45, Leaves 7. A=3.81mm, B=1.57mm, C=10mm, D=28mm & E=50mm
CP289 - Module 0.50, Leaves 7. A=4.24mm, B=1.75mm, C=15mm, D=55mm & E=95mm
CP2812 - Module 0.65, Leaves 7 .A=5.51mm, B=2.27mm, C=15mm, D=55mm & E=95mm
CP2813 - Module 0.70, Leaves 7. A=5.93mm, B=2.45mm, C=15mm, D=55mm & E=95mm
CP2815 - Module 0.45, Leaves 8. A=4.26mm, B=2.02mm, C=10mm, D=28mm & E=50mm
